Outer Casing: Die cast aluminium
Fins: Die cast aluminium
Controls: Digital LCD display, controls and screen
Safety: Overheat temperature protection.
IP Rating: IP20
Installation: Wall mounting kit included and must be used.
Installation must comply with current IEE regulations.
The product should be connected to the fixed wiring of the property via a double pole fused spur with a minimum break capacity of 13 amps
Cable pre-wired (1.4m),
Cable entry to the bottom right of the unit.
Electrical Isolation: Class I
Standard Warranty: 1 year parts or replacement warranty.
|Order Code ||Height (mm) ||Width (mm) ||Depth (mm) ||Weight (kg) |
|AVG600T ||575 ||480 ||80 ||8.5 |
|AVG900T ||575 ||560 ||80 ||10.0 |
|AVG1500T ||575 ||800 ||80 ||15.5 |
|AVG1800T ||575 ||960 ||80 ||19.0 |
